What Are The Advantages Of Horizontal Plating?

The development of horizontal electroplating technology is not accidental, but the demand for special functions of high-density, high-precision, multi-functional, and high-aspect-ratio multilayer printed circuit board products is an inevitable result. Its advantages are that it is more advanced than the current vertical rack plating process, the product quality is more reliable, and large-scale production can be realized. Recently, we have combined the two processes together, conducted a detailed comparison, and deliberately summarized the advantages of horizontal electroplating. Let's take a look with the editor today!

Horizontal plating

Advantages of horizontal plating:

(1) In the process review, there is no need to leave the clamping position, which increases the practical area and greatly saves the loss of raw materials.

(2) It can adapt to a wide range of sizes without manual installation and suspension, and realize fully automatic operation, which is very beneficial to improve and ensure that the operation process does not damage the surface of the substrate, and realizes mass production.

(3) The horizontal electroplating is controlled by the whole process computer to ensure the uniformity of the surface and hole coating of each printed circuit board under the same conditions.

(4) From the perspective of management, the electroplating tank will not be out of control due to human error from cleaning, adding, and replacing electroplating solution to fully automatic operation.

(5) It can be seen from the actual production that due to the multi-level horizontal cleaning of horizontal electroplating, the cleaning water is greatly saved and the pressure of sewage treatment is reduced.

(6) Since the system adopts closed operation, the direct impact of pollution to the working space and thermal evaporation on the process environment is reduced, and the working environment is greatly improved. Especially when drying the board, since the heat loss is reduced, unnecessary energy consumption is saved, and the production efficiency is greatly improved.

The above are the advantages of horizontal electroplating compared to vertical electroplating! Hope this article can help you!
